We are proud to offer this CARQUEST product line: CARQUEST Premium Serpentine Belts By Gates
Product Features:
It provides smoother, quieter operation, with less slippage and belt wear to improve belt life and reduce costly maintenance time.
More compact design compared to classical section V-belts and optimally designed for high horsepower, space-constrained applications with small pulley diameter drives
The Flex-Weave coating is a patented fabric construction that protects the belt core from oil, contaminants and heat, thus extending belt life.
Flex-Bond cords are forged into the body of the belt, resisting fatigue and impact, and absorbing bending stresses without damaging the cord.
Precision ground sides for a regular seat and precise placement of the belt in the pulley grooves.
MN = Molded teeth reduce and better distribute thermal and bending stresses.
Patented ethylene elastomer composite construction protects the belt against heat, ozone, and sunlight
Meets ARPM/RMA IP-3-2 oil and heat resistance standards and ARPM/RMA IP-3-3 static conductivity requirements
Temperature Range: -70 Deg. F to +250 Deg. F (-57 Deg. C to +121 Deg. C)
NOTE: Available in 3VX, 5VX, and 8VX cross-sections as well as Super HC Molded Notch PowerBand joined V-belts
Specifications
Belt Material:
Ethylene Elastomer (EE)
Construction:
Notched
Cord Material:
Polyester
Cross Section Designation:
5VX
Notched:
Yes
Outside Circumference:
71 in
Strand Quantity:
1
Top Width:
.62 in
Type:
Narrow Section Molded Notch V-Belt
