NGK Iridium IX Spark Plug (DR8EIX): Outstanding Acceleration & Durability

(1493 reviews)
Part # 6681
60 day warranty
Loading...
Loading...
How Would You Like To Get This Item?

Store Pickup

Loading...Loading...Loading...

Same Day Home Delivery

Loading...Loading...Loading...

Home Delivery

Loading...Loading...Loading...
Loading...
Loading...
Loading...Loading...Loading...Loading...Loading...

Product Information

Product Details
Part No. 6681
Warranty Details (60 Day Warranty)
NGK Iridium IX spark plugs are specifically designed for the performance enthusiast. Iridium IX provides outstanding acceleration, high fuel efficiency and durability. NGK Iridium IX plugs offer extreme ignitability and exceptional anti-fouling. Tapered cut ground electrode provides improved starting, idling and throttle response. The Iridium fine wire center electrode's durability is six times harder than platinum. Iridium alloy's extremely high melting point is perfect for today's engines. For even greater performance consider upgrading to an NGK Ruthenium HX plug.

Product Features:
  • SINGLE IRIDIUM TIP: Fine wire 0.6 millimeter iridium tip center electrode ensures high durability and a consistently stable spark
  • IRIDIUM ALLOY CENTER ELECTRODE: Iridium's density (6x that of platinum) and extremely high melting point is perfect for modern high efficiency engines
  • TAPERED CUT GROUND ELECTRODE: Reduced quenching design produces outstanding ignitability, improved acceleration, fuel efficiency and durability
  • SOLID COPPER CORE: 98% pure copper core offers superior heat dissipation, conductivity and ultra wide heat ranges
  • TRIVALENT METAL PLATING: Delivers superior anti-corrosion and anti-seizing properties, ensuring ease of installation and removal
  • RECOMMENDED USAGE: Modified or high performance applications, or as an upgrade to OE nickel alloy spark plugs
Specifications
Center Electrode Core Material:
Copper

Center Electrode Design:
Fine Wire

Center Electrode Insulator Tip Projection:
0.08 in

Center Electrode Projection:
Mid Projection

Center Electrode Tip Material:
Iridium

Electrical Terminal Type:
Stud

Electrode Core Material:
Iridium

Electrode Tip Material:
Iridium

Gap Size:
0.032 in

Grade Type:
Performance

Ground Configuration:
J-Gap

Ground Electrode Core Material:
Nickel

Ground Electrode Quantity:
1

Ground Electrode Tip Design:
Taper Cut

Ground Electrode Tip Material:
Nickel

Ground Strap Quantity:
1

Hex Size:
18 mm

Insulator Height:
1.99 in

Insulator Material:
Ceramic

Manufacturer Heat Range:
8

Pre-Gap Size:
.032 in

Reach:
0.750 in

Resistance:
5000.0 ohm

Resistor:
Yes

Resistor Type:
Yes

Seat Type:
Flat

Shorty Spark Plug:
No

Skirt:
No

Skirt Length:
0.0 in

Thread Diameter:
0.472 in

Thread Size:
M12 - 1.25

Tip Configuration:
Stud

Washer Type:
Crush

Washer(s) Included:
Yes

Wrench Diameter:
18.00 mm
Loading...
Loading...Loading...Loading...Loading...Loading...
4.8 out of 5
1493 Customer Reviews
96% of respondents would recommend this to a friend
Ratings Distribution
5 Stars
1305
4 Stars
134
3 Stars
21
2 Stars
5
1 Star
28
I would not buy these again.Got me back in the race!! 1st place at Daytona Speedway!Got me back in the race!! 1st place at Daytona Speedway!
Very pleasedDefinitely recommendLike the Iridium sparp plugs.They workOMG so good in my Suzuki bought same brand for my Corvette !
Pros
249
Improves Engine Efficiency
226
Easy To Install
216
Increases Power
137
Durable
45
Lightweight
Cons
16
none
15
No Improvement In Performance
6
Price
6
None
5
Decreases Gas Mileage
Best Uses
238
Everyday Driving
188
Replacement
149
Performance Driving
53
Restoration
48
Racing
Car & Truck
25
Casual Driver
21
Auto Enthusiast
10
Mechanic
10
Truck Enthusiast
7
Competitive Driver
Describe Yourself
129
Casual Driver
127
Auto Enthusiast
65
Mechanic
34
Truck Enthusiast
23
Competitive Driver
Most Liked Positive Review
Mazda 3s - 2.3L N/A - BEST PLUGS!
Recently replaced the long block assembly on a 2005 Mazda3s Hatchback - this being the 2.3 liter non-turbo. carried over all electronics, ...includings plugs :xUnknowingly cracked spark plug # 4 during the motor swap, causing the car to only run on 3 cylinders.Replaced the plugs with cheap-o BOSCH platinums at $2 and change. And when the sales-teenager girl (at a competing parts store... let's call them [@]) stated that they were pre-gapped (according to her trusty computer), I threw them in the car without even checking.The cylinder misfire in #4 was gone, but now I was getting random misfires... causing excess fuel to blow up in my catalytic converter.. my precious, expensive, need-to-pass-emissions catalytic converter.Did a little research, and well, here's the dillie: Mazda uses IRIDIUM spark plugs from the factory. Nothing else. Mazda also uses NGK SPARK PLUGS from the factory. Nothing else. Mazda specified the SPARK PLUG GAP @ .050. Nothing else.****(This only applies to 2005 - 2009 Mazda3s 2.3L motors. The 2004 Mazda3 2.3L had a different ignition setup).****Anyways, I went out, bought these plugs along with a SPARK PLUG GAP TOOL, RE-GAPPED (they were all at .030, made them .050) and installed these plugs. The car started up immediately. During the delightful 106,990 miles I drove the car before oil-starvation lead to a quite unpleasant rod-knock, the car never started this good.And here's to Advanced Auto Parts being the only place that had these plugs. On a Sunday.Thank you Advanced Auto Parts.Lesson learned: Always check your oil so you don't have to go through what I just did.
Most Liked Negative Review
NGK Iridium
I have a 2003 Nissan Pathfinder LE and I used this kind of plugs. Within 45,000 miles ran the engine produces smoke on the tailpipe. It was a lot of puzzled that arise within me, considering that the NGK company proclaimed as spark plug world leader!When I let the mechanic changed the plugs they showed it to me, the was in bad shape After, with lot of research, I decided to replaced them and bought the Bosch Iridium. I was convinced with this, due to the bosch video that I watched. It was created in a quality wise. And now I have those in in my engine and I'm fully satisfied, with smooth acceleration, quicker response,improved fuel economy and durability. Finally I would conclude that Bosch Iridium is much better than Ngk Iridium, besides Boch is cheaper than NGK.I'm a happy Bosch Iridium user.
Reviewed by 1493 Customers
Great product with noticeable difference
Great product and well worth the money! They brought my 5.9L back to life and it has 170k miles on it! More pickup, smooth idle and improved responsiveness.
Bottom Line Yes, I would recommend to a friend
Best spark plugs for the money.
Staff Reviewer -
Greatly improving my mpg in my silverado.
Bottom Line Yes, I would recommend to a friend
Wrong plug for toyota
Here is the right plug for 2006 toyota 6 cycl LFR6AIX-11 If any one is interested
Bottom Line Yes, I would recommend to a friend
Great Performance and great on GAS!
You could Feel the difference in power. And Your car response to the throttle its a no brain er! You have to get them!
Bottom Line Yes, I would recommend to a friend
Mazda 3s - 2.3L N/A - BEST PLUGS!
Staff Reviewer -
Recently replaced the long block assembly on a 2005 Mazda3s Hatchback - this being the 2.3 liter non-turbo. carried over all electronics, ...includings plugs :xUnknowingly cracked spark plug # 4 during the motor swap, causing the car to only run on 3 cylinders.Replaced the plugs with cheap-o BOSCH platinums at $2 and change. And when the sales-teenager girl (at a competing parts store... let's call them [@]) stated that they were pre-gapped (according to her trusty computer), I threw them in the car without even checking.The cylinder misfire in #4 was gone, but now I was getting random misfires... causing excess fuel to blow up in my catalytic converter.. my precious, expensive, need-to-pass-emissions catalytic converter.Did a little research, and well, here's the dillie: Mazda uses IRIDIUM spark plugs from the factory. Nothing else. Mazda also uses NGK SPARK PLUGS from the factory. Nothing else. Mazda specified the SPARK PLUG GAP @ .050. Nothing else.****(This only applies to 2005 - 2009 Mazda3s 2.3L motors. The 2004 Mazda3 2.3L had a different ignition setup).****Anyways, I went out, bought these plugs along with a SPARK PLUG GAP TOOL, RE-GAPPED (they were all at .030, made them .050) and installed these plugs. The car started up immediately. During the delightful 106,990 miles I drove the car before oil-starvation lead to a quite unpleasant rod-knock, the car never started this good.And here's to Advanced Auto Parts being the only place that had these plugs. On a Sunday.Thank you Advanced Auto Parts.Lesson learned: Always check your oil so you don't have to go through what I just did.
Bottom Line Yes, I would recommend to a friend
